By Order of Sanmina - SCI Systems Israel Ltd
•
MAKINO MC-65 (8) Pallet CNC Horizontal FMS System. S/N. A-91-866 (1990);
Axis Travels: X = 630 MM (25"), Y = 560 MM (22"), Z = 510 MM (20"); Table Type: Pallet Loading; Indexing Angle: 360 Position (1 Deg.); Pallet Size: 500 MM (19.685") x 500 MM (19.685"); Max. Weight on Pallet: 1,000 KG (2,200 LBS); Spindle Center to Table Top: 100 ~ 660 MM (4 ~ 26"); Spindle Nose to Pallet Center: 200 ~ 710 MM; Spindle Nose: 7/24 Caper No. 50; Spindle Speed: 10 ~ 4,000 RPM (SD Digit Direct Command); Spindle Drive Motor: 15 KW (20HP); Spindle Run Hours: 37,700; ATC: 99; Fanuc 15 M CNC Control; BEARINGS CHANGED IN LAST 5 YEARS
•
MAKINO MC-98 (2) Pallet CNC Horizontal Machining Center. S/N. A-91-350 (1990);
Axis Travels: X = 915 MM (36"), Y = 810 MM (31.9"), Z = 750 MM (29.5"); Indexing Angle: 360 Position (1 Deg.); Pallet Size: 630 MM (24.8") x 630 MM (24.8"); Max. Weight on Pallet: 1,000 KG (2,200 LBS); Spindle Nose: 7/24 Caper No. 50; Spindle Speed: 10 ~ 4,000 RPM (SD Digit Direct Command); Spindle Drive Motor: 15 KW (20HP); Spindle Run Hours: 16,970; ATC: 60; Fanuc 15 M CNC Control.
•
MAKINO FNC178-A (2) Pallet CNC Vertical Machining Center. S/N. A-91-390 (1990);
Axis Travels: X = 1,700 MM (67"), Y = 800 MM (32"), Z = 700 MM (27.5"); Table Type: (2) Pallet Changer; Pallet Size: 700 MM (27.559") x 1,800 MM (70.86"); Max. Weight on Pallet: 3,500 KG (7,700 LBS); Spindle Center to Table Top: 225 ~ 925 MM (9 ~ 36.5"); Spindle Nose to Pallet Center: 200 ~ 710 MM; Spindle Nose: ISO No. 50; Spindle Speed: 10 ~ 3,500 RPM (SD Digit Direct Command); Spindle Drive Motor: 15 KW (20HP); Spindle Run Hours: 18,800; ATC: 50; Fanuc O-M CNC Control.
Perfection Industrial will be pleased to assist prospective buyers in obtaining quotes for dismantling, removal, packing to container and shipping quotes if required. Please contact us if you require further assistance.
